3 Phase Ac Surge Protection Device

CNKA3 phase ac surge protection device Introduction

China Manufacturers CNKA offers the latest selling 3-phase AC surge protection devices suitable for installation in AC 50/60Hz systems with a voltage of 380V, including TN-STN-C-STATIT and other power systems. These devices are designed for use at the connection points between LPZ1 or LPZ2 and LPZ3. They comply with IEC61643-1 and GB188021 standards, utilizing a 35mm standard rail surge protective device module and equipped with a fault release mechanism for enhanced safety and reliability.

CNKA3 phase ac surge protection device Parameter (Specification)

CNKA3 phase ac surge protection device Feature

The TN-S or TN-C-S system is an electrical configuration where the neutral and grounding wires are separated at the source to ensure a reliable grounding connection. This setup is typically linked to transformer grounding, which helps minimize cable breakage and L-PE faults. However, this system can be relatively expensive due to higher costs associated with cables, installation, and ongoing maintenance.

CNKA3 phase ac surge protection device Details

CNKA3 phase ac surge protection device Dimensions and wiring

CNKA3 phase ac surge protection device Basic components

1  The discharge gap, often referred to as the protective gap, typically consists of two metal rods spaced apart at a specific distance and exposed to air.

2  A gas discharge tube comprises a pair of separated cold cathode plates, sealed within a glass or ceramic tube filled with an inert gas, such as argon.

3  A varistor is a nonlinear resistor made of metal oxide semiconductor, primarily composed of ZnO, and its resistance is highly sensitive to voltage changes.

4  The suppression diode serves as a final protective component in multi-level protection circuits, offering clamping and voltage limiting functions, along with advantages like low clamping voltage and rapid response time.

5  A choke coil is a common mode interference suppression device that utilizes ferrite as its magnetic core.

6  The 14-wavelength short circuit breaker is a microwave signal surge protection device developed based on lightning wave spectrum analysis and the standing wave theory of antennas and feeder lines.
