200A Circuit Breaker DC Mccb
  • 200A Circuit Breaker DC Mccb200A Circuit Breaker DC Mccb
  • 200A Circuit Breaker DC Mccb200A Circuit Breaker DC Mccb
  • 200A Circuit Breaker DC Mccb200A Circuit Breaker DC Mccb
  • 200A Circuit Breaker DC Mccb200A Circuit Breaker DC Mccb

200A Circuit Breaker DC Mccb

CNKA is a specialized electrical manufacturer dedicated to the development, testing, tooling design, manufacturing, and assembly of 200A Circuit Breaker DC Mccb. Our capabilities encompass injection molding, punching, welding, and wiring. We are committed to adhering to the highest quality standards, including ISO 9001 and TS16949 quality management systems.

The CNKA customized 200A DC MCCB (Molded Case Circuit Breaker) from China Suppliers represents an advanced upgrade in circuit breaker technology, combining global best practices with tailored features for both domestic and international markets. With an insulation voltage reaching 1000V, it is ideal for distribution systems rated between 10A to 630A. This MCCB serves crucial roles in energy distribution, circuit protection against overloads, short circuits, and undervoltage conditions in power equipment. It also offers essential motor protection against starting issues and overloads, ensuring compliance with ISO and TS quality management standards.



CNKA 200a circuit breaker dc mccb Parameter (Specification)



   TECHNICAL DATA

   Type



YTTM1-125/PV2

YTTM1-250/PV2

YTTM1-400

 YTTM1-630

   Pole



2P







   Max Rated Current



125A

250A

400A

630A

   Electrical Characteristics











   Rated Working Voltage

Ue

500V DC







   Rated Current

In(A)

63A,80A,100A,125A

125A,160A,200A,250A

315A

500A

   Rated Insulated Voltage

Ui

550VDC



350A

630A

   Rated Impulsed Voltage

Uimp

8KV



400A



 1Min Power Frequency WithstandVoltage



3.8KV







   Ultimate Breaking Capacity

Icu

15kA

20kA

25kA

35kA

   RunBreaking Capacity

Ics

15kA

20kA

25kA

35kA

   Protection



Thermal Magnetic Type







   Tripping Type











   Control And Indication



Optional







   Control Manual

Direct(RHD)

Optiona

164.5×79.5×118mm





Extended(ERH)

Optional







   Mode    MOD



Optional







   Shunt Release(SHT)



Optional







   Auxiliary Release



Yes







   Terminal End Cover



Yes







   Interphase Barriers











Service Life/Cycle Operation











   Mechanical



10000







   Electrical



2000







   Size(L×W×H)



150.5×64.5×119mm







   Ingress Protection



All Sides IP40,Connection Terminal IP20







   Installation Environment











   Comply With



IEC60947-2/GB14048.2







   Storage Temperature



-40℃~+85℃











CNKA 200a circuit breaker dc mccb Feature



1  This breaker provides both overload protection and short circuit protection functions.

2  It features compact size, high breaking capacity, and rapid response.

3  It can operate reliably in ambient temperatures ranging from -25°C to +70°C, with a daily average temperature not exceeding +35°C.

4  It is suitable for environments where the relative humidity at the highest temperature does not exceed 50%, and under lower temperatures, the monthly average minimum temperature for humidity testing should not be above +25°C, with an average relative humidity not exceeding 90%.



CNKA 200a circuit breaker dc mccb Details





CNKA 200a circuit breaker dc mccb Dimensions and wiring




CNKA 200a circuit breaker dc mccb FAQ

Q: Are you open to using our logo?

A: If you meet the minimum quantity requirements, we are fully supportive of pursuing OEM arrangements.

Q: What role do surge protection devices play in PV systems?

A: To safeguard both residential and large-scale PV installations, adherence to precise design standards is crucial. Installing lightning arresters and surge protection devices (SPDs) is essential to preemptively protect the system and mitigate potential power surges.
